Electronics |
Nordic Semiconductor nRF52832 Microcontroller IR receiver LIS2DH/LIS3DH accelerometer; motion and orientation detection Temperature Sensor Two buttons |
|
|
Connectivity |
Bluetooth |
Bluetooth Low Energy 5.0 |
|
Range |
Up to 98 feet (30 meters) |
|
|
Power |
Batteries |
CP224147 |
|
Battery life |
3 years with IR active, 5 years with 1 Hz beaconing |
|
|
Replaceable |
No |
|
|
Physical |
Dimension |
2.55 in x 4.21 in x 0.29 in (65 mm x 107 mm x 7.5 mm) |
|
Weight |
1.02 oz (29 grams) |
|
|
Casing |
IP 65 |
|
|
Buttons |
Two programmable call buttons, red and blue |
|
|
Environmental |
Operating Temperature |
32°F to 131°F (0°C to 55°C) |
|
Operation Humidity |
10% to 90% non-condensing |
|
|
Operating Modes |
Over-the-Air configuration; cloud management Beacon broadcasting IR scanning for room-level tracing Environmental temperature sensing Motion detection Button call (push) event |
