When you're ready to begin deploying a Kontakt.io solution and have your devices onsite, the following provides references to get started.
You'll need to configure each Portal Light with the facility's local Wi-Fi network to allow its connection to Kio Cloud and complete the Portal Light install steps from the Kio Setup Manager app.
Portal Light configure and install instructions
IMPORTANT: if your deployment includes Portal Lights, set up and install these devices first.
Deployment and installation is dependent on the occupancy solution being deployed.
Room Occupancy deployment guide
Seat-Level Occupancy deployment guide
Footfall Traffic deployment guide
By default, an Asset Tag 2 is delivered with its power on. In this article, you'll learn how to verify an Asset Tag 2 is powered on and how to turn it on or off.
To verify if the tag is powered on, press and quickly release either the blue or red button. Look for the LED to blink for a few seconds as a confirmation it's powered on.
Warning
Continuously pressing either of the tag's buttons may result in activating a button press event. If you do not see an LED flashing after a button press, do not press a button for 5 seconds to allow the tag to clear the previous button event.
If a tag's LED does not blink after pressing and quickly releasing either the blue or red button, follow these steps to turn it on:
-
Press and hold either the blue or red button for 5 seconds.
-
Once you observe the LED blinking, it indicates that the tag is now turned ON.
To turn off a tag, follow these steps:
-
Press and hold either the blue or red button for 5 seconds.
-
Once the LED stops blinking, it indicates that the tag has been turned OFF.
To program the buttons for an Asset Tag 2 to trigger an excursion event (alert) when a button is pressed, a policy is required to be created for each of its buttons. Policies are created and managed from the Kio Cloud Policy Foundry app.
To program the buttons for an Asset Tag 2 to trigger an excursion event (alert) when a button is pressed, a policy is required to be created for each of its buttons. Policies are created and managed from the Kio Cloud Policy Foundry app.
When you receive a Smart Badge from Kontakt.io, it is powered ON and ready for use.
To verify a badge is ON, press and quickly release the BLUE or RED button and verify you see its LED blink for a few seconds.
If you did not see the LED blinking, you'll need to turn it ON. Press and hold the BLUE or RED button for 5 seconds. When you see the button LED blink, it's your confirmation the badge is ON.
NOTE: continuously pressing either button may result in activating a button press event. If you do not see an LED blink after a button press, do not press a button for 5 seconds to allow the device to clear the previous button event.
When you're ready to use a Nano Tag, you'll need to power it ON.
Press and hold its front side for 3 to 5 seconds and release when you see its LED blink. When its LED consecutively blinks up to 5 times, the Nano Tag is ON and ready for use.
|
|
|
Once turned on, a Nano Tag has up to a 3-month battery life with the standard factory default settings (Tx power +2.5 dBm, Interval 1000 ms; 1Hz, single channel).
