Parameter |
Specification |
|---|---|
|
Physical |
Height: 2.28 in (58mm) Width: 2.28 in (58mm) Depth: 0.46 in (11.8 mm) Weight: 1 oz (28 grams) Casing IP rating (protection): IP65 (water-resistant) Tamper-proof casing: No Flammability rating: UL V0 (anti-flammable) IR front color: Black Button: One programmable button. Flat, low-profile button to minimize accidental presses. |
|
Environmental |
Operating temperature: -40ºF to +158ºF (-40°C to +70°C) Storage temperature: Recommended: ≤+86ºF (≤+30°C) | Absolute min/max: -40ºF to +158ºF (-40°C to +70°C) Operating humidity: 10%-95% RH (non-condensing) Storage humidity: 5%-95% RH (non-condensing) Storage shelf life: 2 years |
|
Battery Power |
Battery life: Up to 4 years with IR and factory default settings Number of batteries: 1 cell Total capacity: 1900 mAh Replaceable: No Power activation: Button long press (5s) to power ON. TurningOFF disabled by factory default. |
|
Bluetooth Low Energy Radio |
Wireless standard: Bluetooth LE 5.4 Range: Up to 230 feet (70 meters) in open space Frequency range: 2.402GHz -2.480GHz Sensitivity: -96 dBm Bluetooth LE 1 Mbps Output power: -20 dBm to +4 dBm programmable levels |
|
Sensors and Peripherals |
IR (Infrared) sensor: IR photo-detector and preamplifier with advanced noise--suppression, enhanced sensitivity and wide angle view Ambient Temperature sensor range: -40ºF to 185ºF (-40°C to 85°C) Accuracy at +25°C: ± 2.5°C Accelerometer: Ultra low-power high performance 3-axis accelerometer Button sensor: BLE-burst feature upon button press—for guaranteed signal delivery Vibration motor: Badge briefly vibrates when a button press event is emitted. |
|
Certifications |
FCC, CE, UKCA, Reach/TSCA, RoHS, WEEE |
Bluetooth LE parameters
|
Parameter |
Factory default* |
Configurable |
|---|---|---|
|
BLE packets |
Kontakt.io Location |
Yes; Kontakt.io Location, Telemetry, iBeacon, Eddystone |
|
BLE interval |
1000ms |
Yes |
|
BLE name |
Kontakt |
Yes |
|
iBeacon major, minor, UUID |
Random |
Yes; custom request |
|
TX power |
-4 dBm |
-20 to +4 dBm |
IR parameters
|
Parameter |
Factory default* |
Configurable |
|---|---|---|
|
IR listening interval |
4s |
Yes Warning: Receiver’s interval should be set to 1s or multiples of 2s to properly receive IR signal. Changing this setting will heavily impact device battery lifetime. |
|
IR power saving |
On |
Yes; on/off |
|
IR listening duration |
2s |
Yes |
Button and sensor parameters
|
Parameter |
Factory default* |
Configurable |
|---|---|---|
|
Turn off with long button press |
Disabled |
Yes; enable/disable |
|
Button press event |
Triple press for Staff Safe Single press for RTLS |
Yes; single press/triple press |
|
Temperature |
Off |
Yes; on/off via Telemetry packet |
|
Accelerometer raw data (x,y,z) |
Off |
Yes; on/off via Telemetry packet |
|
Vibration motor |
On |
No |
* Custom or use-case configurations can be requested at the time of order placement.
