Note: Discontinued device. This device is no longer available for purchase and all support has been discontinued. This includes firmware updates and technical assistance.
Recommended replacement model: Puck Beacon technical specifications
| Dimensions and weight | Height | 3.7 in (94 mm) |
| Width | 2.28 in (58 mm) | |
| Depth | 1.38 in (35 mm) | |
| Weight | from 3.56 oz (101 grams) | |
| Electronics | Microcontroller | Nordic Semiconductor nRF52832 |
| Connectivity | Bluetooth | Bluetooth 4.2 compliant, Bluetooth 5 compatible |
| Range | up to 230 feet (70 meters) | |
| Available transmission power levels |
-20 to +4 dBm | |
| Sensitivity | -96dBm | |
| Battery and power | Model | CR 2477 |
| Type | Lithium Manganese Dioxide Coin Battery | |
| Total capacity | 2000mAH | |
| Replaceable | Yes | |
| Battery life | Up to 4 years (Tx 12dBM / Interval 350ms) | |
| Activation | Battery separator | |
| Sensors | Accelerometer Temperature |
|
| Button | Lexan keyboard connection type |
FPC connector is mounted on PCB to accept flat cable from Lexan keyboard LED and buttons are part of Lexan keyboard |
| Functionalities | RTC Dataflash memory |
|
| Casing | Material | PC |
| Colors | Light grey | |
| Protection | IP 65 | |
| Mounting | 1 mounting hole | |
| Antibacterial surface | No | |
| Environmental requirements | Operational temperature | -77°F to 185°F (-20°C to 60°C) |
| Humidity | 0% to 95% non-condensing | |
|
Beacon standards compatibility |
iBeacon | Yes |
| Eddystone | Yes | |
| Kontakt.io Secure Profile | Yes | |
| Custom frames available | Yes | |
| Warranty | 1 year |
