Electronics |
ESP32 microcontroller |
|
|
Connectivity |
Wi-Fi |
Wireless networking protocols: 802.11 b/g/n (802.11n up to 150 Mbps) 2.4 GHz ~ 2.5 GHz Wireless security protocols: Open, WEP, WPA (TKIP & AES), WPA2 (TKIP & AES) - Personal and Enterprise modes Wireless authentication protocols: EAP-TLS, EAP-TTLS (MSCHAPv2), PEAP v0 (MSCHAPv2) Network communication protocols: Hypertext Transfer Protocol Secure (HTTPS)/TLS 1.2 IP addressing: Dynamic Host Configuration Protocol (DHCP) Data Packet Size: typically less than 6 kilobytes (kB) per second |
|
Bluetooth |
Bluetooth v4.2 BR/EDR and BLE specification Range: up to 165 feet (50 meters) |
|
|
Power US model |
Type B Plug |
Input voltage: 110VAC (accepted range 90V-240VAC) Output voltage: 110VAC (same as input) Max load current: 16A Max load: 3520W |
|
Power EU model |
Type E Plug (grounded) & Type F |
Input voltage: 90V-240VAC Output voltage: 90V-240VAC Max load current: 16A Max load: 250V |
|
Power UK model |
Type G Plug |
Input voltage: 90V-240VAC Output voltage: 90V-240VAC Max load current:16A Max load: 3000W |
|
Environmental Requirements |
Operating temperature |
32°F to 104°F (0°C to 40°C) |
|
Operating humidity |
10% to 90% non-condensing |
|
|
Physical Specification |
Dimension |
4.33 x 2.45 x 1.37 in (110 x 62.3 x 34.9 mm) |
|
Weight |
5.64 oz (60 grams) |
|
|
Passthrough outlet |
Push button to enable/disable |
|
|
Status indicator |
RGB LED |
|
|
Certifications |
FCC and UL Certificate information provided on device packaging |
Specifications subject to change without notice.
