The Kontakt.io Portal Beam is a wireless, Bluetooth Low Energy (BLE), cloud-based sensor platform that quantifies rooms and delivers building insights in real-time. The Portal Beam has an 8-core CPU with neural network architecture and Bluetooth Low Energy (BLE) 5.0 readiness, Infrared (IR) beaconing, RSSI fingerprinting, thermal camera, and environmental sensors. The Kontakt.io Portal Beam's powerful occupancy and traffic measurement capabilities can deliver complete visibility into your spaces, as well as support the whole spectrum of space utilization use cases and deliver insights and analytics to help you understand how spaces are being used.
-
Occupancy & Footfall Traffic
Room Occupancy: detects and measures the presence of people in enclosed rooms or open spaces.
Seat-Level Occupancy: detects and measures the presence of people in multi-seat workstations.
Footfall Traffic Counting: detects movement and counts people entering and exiting a space defined by an adjustable threshold line.
-
Environmental Monitoring
Environmental sensors measure the ambient air temperature, relative humidity, ambient light level, and calculated Air Quality Index (AQI) level.
-
Asset and Badge Tracking
With built-in infrared (IR) beaconing and RSSI fingerprinting capability provides room-level location
-
Mobile Indoor Navigation
With a built-in infrared (IR) beaconing, Portal Beams are the infrastructure for mobile-based wayfinding apps and SDKs. With Portal Beams deployed in every room, there is no additional need for a standalone infrastructure.
-
Plug-and-Play
Integrates wirelessly with enterprises’ existing Wi-Fi infrastructure, eliminating the need for cabling or rewiring. This is accomplished through a BLE to Wi-Fi infrastructure including either Kontakt.io Portal Lights or third-party BLE compatible Access Points, such as the Cisco Catalyst Access Points.
