| Electronics | Microcontroller nRF52832 IR Beam (4-directional LEDs) Environmental sensors: humidity, pressure, temperature, air quality, light sensor Buzzer (optional) Far-Infrared wide-angle thermal camera |
|
| Connectivity | Bluetooth | Bluetooth Low Energy 5.0 |
| Range | up to 165 feet (50 meters) | |
| Environmental Sensors | Temperature | Range: -40°F to 185°F (-40°C to 85°C) Typical accuracy: +/- 1° |
| Relative Humidity | Range: 0-100% Typical accuracy: 20-80% RH, +25°C/F |
|
| Air Quality Index | Range: 0 - 255 Value calculated based on multiple sensor readings |
|
| Pressure | Range: 300-1100 hPa Typical accuracy: 0.6 hPa |
|
| Light | Range: 1-100% | |
| Power | Input Voltage | DC 6V-24V barrel type terminal |
| Batteries | 6 AA Lithium 3.6V, 15.6 Ah (ER14505) 4-year battery life with factory default configuration |
|
| Environmental | Operation Temperature | 64.4°F to 77°F (18°C to 25°C) |
| Operation Humidity | 10% to 90% non-condensing | |
| Physical Specification | 7x7x1.8 in (18x18x4.6 cm) Dedicated mounting plate Reset button RGB LED status indicator (information & alerting) |
