Intro to Kio Setup Manager – Knowledge Base

Kontakt.io's Kio Setup Manager is a mobile app that delivers Device Management tools—including the installation of Infrastructure devices (Portal Light, Beams, Beacons, Temp Monitors) and access to view and manage the basic configuration of Tag devices (Asset Tags, Nano Tags, Sticker Tag, Smart Badges). In addition, the app provides local device troubleshooting and configuration tools.

Topics include:

Things to know
Download the Kio Setup Manager app
Navigating the app
Features at-a-glance by device

Things to know

User access requirements. You must be assigned to a Device Management role. A role determines your permission level and which devices you can access. For example, a user assigned the Device Management Administrator role has full permissions to all devices. For more information, see Manage user access to Device Management.
Account type. You'll need to know if your organization's account is a Tenant or Non-Tenant type. You can identify the account type from the URL used to sign in from a web browser.

Tenant account type: You sign in to Kio Cloud from an unique URL that includes the Tenant ID. Example: https://[Tenant ID].app.cloud.[us or uk].kontakt.io.

Non-Tenant account type: You sign in to Kio Cloud from https://app.cloud.us.kontakt.io or https://app.cloud.uk.kontakt.io.
Account Region. During sign in, you'll need to select the region of your organization's account.

The Region is also located in the account URL (https://[Tenant ID].app.cloud.[us or uk].kontakt.io).
Use Instabug to report issues. If the app shows an error notification or you notice another problem, report it right away through Instabug (integrated in the app). Learn how.

Download the Kio Setup Manager app

Kontakt.io Infrastructure devices, those that remain in a fixed, stationary position, are required to be installed using the Kio Setup Manager mobile app. If you already have the app, be sure you have the latest version.

To download the app, go to the App Store or Google Play. Search for Kio Setup Manager.

Device compatibility: iPhone or iPad: iOS version 16 or later | Android phone or tablet: version 8 or later
Connectivity: Bluetooth enabled | Wi-Fi connection with Internet

Navigating the app

Home: snapshot of device health (only includes devices with a Deployed status) and account sign-in profile.

Top-right icon: view account details or log out.

Gateways: number of Portal Lights currently online or offline.

Inventory: total number of deployed devices (Deployment Status is Deployed)

Pending: number of devices with a pending configuration update. For environments without a Portal Light infrastructure, you must run a Telemetry Sync to complete the update

Battery Levels: status of device batteries across all deployed battery-powered devices.
Devices: list of Kontakt.io devices.

Nearby Devices (default view): devices within Bluetooth range.

My Devices: devices you have access to but that are not within Bluetooth range.

Search, sort, or filter by model, order ID, pending configuration, or deployment status.
Scan: view a device and its available actions by scanning its QR code.
Install: step-by-step guidance to install Infrastructure devices— Portal Light, Portal Beam, Beam Mini, Anchor Beacon, Dispeser Beacon, Temp Monitor Pro, Temp Monitor Lite.
Tools: validation and troubleshooting features in one place, including:

Location Validation: a tool to validate the real-time, physical location of a Tag to its last received location in the cloud.

Telemetry Sync: a tool to synchronize nearby devices’ battery levels and other telemetry data with the cloud over the mobile device's internet connection. A helpful tool for those without a Portal Light infrastructure or when troubleshooting device data being received by the cloud.

Beam Troubleshooting: tools for the Portal Beam and Beam Mini.

Portal Beam only: Validate Thermal Image (capture real-time thermal image, view and add Exclusion Zones). Recalibrate Thermal Camera (resets calibration to environment).

Portal Beam and Beam Mini: tool checks whether a Beam is correctly transmitting room-level location data through infrared (IR) and whether Tags (with IR enabled) located in the room location can receive it.

Portal Light Troubleshooting: generate Diagnostic Report to get it settings (Wi-Fi connection and online status). Collect Logs to share with Kontakt.io Support.

Features at-a-glance by device

The following provides an overview of the Kio Setup Manager features by Kontakt.io device models.

Legend: = Available | = Not available or applicable

Infrastructure devices

Feature	Portal Light	Beams (Portal Beam, Beam Mini)
Show Details View configuration, flash LED, reset battery level, upgrade firmware.
Install Install device with in-app guided steps.
Track Device Helps locate a lost or hard-to-spot device by showing your proximity to it based on its RSSI (signal strength).
Test IR Use to validate if a Portal Beam or Beam Mini is correctly transmitting the room number via infrared (IR) and whether nearby Tags or Badges can receive it. Helpful when troubleshooting IR-based room location detection.
Assign Location Update a Portal Light's location when it's being relocated to a new location.		(complete install action)
Replace Portal Lights To replace a Portal Light with new Portal Light.		(complete install action)
Collect Logs & Diagnostic Report Provides additional data for Kontakt.io Support to troubleshoot Portal Light network or cloud connectivity.
Configure NTP Update NTP Servers (primary, secondary).
Portal Beam Thermal Camera—Validate, Recalibrate Validate Thermal Camera: capture a real-time thermal image and view and add Exclusion Zones. Recalibrate Thermal Camera: resets its calibration to the installed environment.		(Portal Beam only)
Firmware upgrade (Show Details) Upgrade device to available firmware version.	(Device Management—scheduled)
Flash LED (Show Details) Device LED will briefly flash—a method to visually identify a device.
Synchronize Internal State (Show Details) Synchronizes internal real-time clock, firmware version, status, and configuration. Primary use case is when a device's local time/date is not correct.

Temperature Monitoring devices

Feature	Temp Monitor Pro	Temp Monitor Lite
Show Details View configuration, flash LED, reset battery level, upgrade firmware.
Install Displayed only for first-time install; set what's being monitored (Storage Unit/Room, or both), Threshold Setting, Location.
Reconfigure Device Update what's being monitored (Storage Unit/Room, or both), Threshold Setting, Location.
Configure Probes Replace existing Storage Unit probe or update Threshold Setting.
Configure Ambient Sensor Assign Location, Threshold Setting.		(complete reconfigure device)
Turn on/off Paused Mode When on, local and cloud alerts are disabled but readings are continued to be logged.
Synchronize Data Uploads the locally stored readings to the cloud. To be completed when the cloud has missed readings due to a network or Bluetooth connection issue.
Download Monitoring Data Download a CSV file with the last 48 hours of readings.
Firmware upgrade (Show Details) Upgrade device to available firmware version.
Synchronize Internal State (Show Details) Synchronizes internal real-time clock, firmware version, status, and configuration. Primary use case is when a device's local time/date is not correct.

Tags and Badges

Feature	Asset Tag	Smart Badge	Nano Tag	Sticker Tag
Show Details View configuration, flash LED, reset battery level, upgrade firmware.
Evaluate Location (Location Validation) Validate the location of a Kontakt.io Tag—helpful when there’s a discrepancy between a Tag's location in the cloud and its real-time physical location.
Track Your Device Helps locate a lost or hard-to-spot device by showing your proximity to it based on its RSSI (signal strength).
Activate (NFC) NFC is required to be activated for use.
Firmware upgrade (Show Details) Upgrade device to available firmware version.
Flash LED (Show Details) Device LED will briefly flash.
Synchronize Internal State (Show Details) Synchronizes internal real-time clock, firmware version, status, and configuration. Primary use case is when a device's local time/date is not correct.
